4

P-2500 REV 2 5/24/2013

Figure C

3. Remove the three (3) bolts securing the compressor mounting bracket to the vehicle,

remove from vehicle (Figure D).

Figure D



TO DISCONNECT THE AIR LINE- USE TWO (2) FINGERS TO
PUSH UP ON THE AIR LINE FITTING (ORANGE RING) WHILE
PULLING DOWN ON THE AIR TUBE.
