2 REV 5 22/01/2013 P-2213
P -2213
ARNOTT AIR SUSPENSION COMPRESSOR
FOR 1997-2006
FORD EXPEDITION/LINCOLN NAVIGATOR
AIR SUSPENSION COMPRESSOR REMOVAL
1. TURN THE AIR SUSPENSION SWITCH TO THE OFF POSITION. (REFER TO THE OWNER’S MANUAL FOR
SWITCH LOCATION).
2. OPEN THE HOOD OF THE VEHICLE.
3. UNBOLT AND REMOVE THE WINDSHIELD WASHER RESERVOIR TANK TO GAIN ACCESS TO THE COMPRESSOR
ASSEMBLY.
4. DISCONNECT THE AIR LINES BY FIRST DEPRESSING THE ORANGE COLORED QUICK-CONNECT LOCKING
RINGS WHILE PULLING SIMULTANEOUSLY OUTWARD ON THE AIR LINE.
5. CAREFULLY DISCONNECT THE ELECTRICAL CONNECTOR.
6. UNBOLT THE THREE (3) FASTENERS RETAINING THE COMPRESSOR ONTO THE VEHICLE, NEXT REMOVE
THE ASSEMBLY FROM ITS MOUNTING LOCATION.
GENERAL INFORMATION:
Reading this manual signifies your agreement to the terms of the general release, waiver of liability, and hold harmless agreement,
the full text of which is available at www.arnottinc.com.
• Not to be stored below 5
o
F (-15
o
C) and above 122
o
F (50
o
C).
• Avoid damage to air lines and cables.
• Removal and installation is only to be performed by fully qualified personnel.
• Use car manufacturer’s diagnostic software.
CAUTION: Damage to the vehicle and air suspension system can be incurred if work is carried out in a manner other than specified
in the instructions or in a different sequence.
To avoid the possibility of short circuits while working with electric components consult your owner's manual on how to
disconnect your battery.
Consult your vehicle owner's manual, service manual, or car dealer for the correct jacking points on your vehicle and for
additional care, safety and maintenance instructions. Under no circumstances should any work be completed underneath
the vehicle if it is not adequately supported, as serious injuries and death can occur.
