AIPTEK PocketCinema N100 - Manual (Page 14)

User’s Manual
Page 14
EN
Specifications
Item Description
Optical Technology DLP
Light Source RGB LED
Aspect ratio 16:9
Resolution 854 x 480 Pixels (WVGA)
Contrast Ratio 1000:1
Projection Image Size 36 cm ~ 305 cm (14” ~ 120”)
Projection Distance 50 cm ~ 425 cm (20” ~ 167”)
Throw Ratio
(Diagonal: Distance)
1.6 (Projection Distance/Width of Image)
Brightness Up to 100 Lumens
Focus Manual
Offset 100%
Connections
HDMI / MHL: Comply with HDMI v1.3 and MHL v2.0
VGA: Mini D-sub 15-pin
AV port: Audio out: 3,5mm mini jack
USB port: Charging the mobile devices
Internal Speaker Mono
Power Supply Input: 100 ~ 240V AC
Output: 12V, 2A DC
Battery Type Embedded 7.4V/2000 mAh Li-polymer battery
Battery Life Enhanced mode : 90 min
Normal mode: 120 min
Eco mode: 150 min
Power Consumption AC mode: 10.5 W
Battery mode: 6.5 W ~ 10.5 W
Dimensions ( L x W x H ) 132 x 95 x 25 mm
Weight 270 g
Humidity 20 – 80%, 80% (Max.), non-condensing.
Operating Temperature 5°C – 35°C.
