16 ASUS Essentio Desktop PC
Using the Portable HDD (optional)
The front panel of the Portable HDD includes one Power/
Status LED indicator. This LED lights up when the Portable HDD is
powered on and blinks when data is being read from or written
to the Portable HDD.
Power/Status
LED indicator
The back panel of the Portable HDD includes one eSATA port and
one mini USB port.
eSATA
port
Mini USB
port
• To use the Portable HDD on your ASUS Essentio Desktop PC,
insert it into the Portable HDD bay.
• To use the Portable HDD on a non-ASUS Essentio Desktop PC,
connect one end of a USB cable to the mini USB port at the
back of the Portable HDD and the other end to a free USB port
on the PC.
For faster data transmission rate, also connect one end of an
eSATA cable to the eSATA port at the back panel of the
Portable HDD and the other end to an eSATA port on the PC.
