ASUS RS700-X7/PS4
4-3
Internal connectors
Page
1.
Serial ATA connectors
(SATA 6Gb/s: 7-pin SATA1, SATA2 [Blue])
(SATA 3Gb/s: 7-pin SATA3, SATA4, SATA5, SATA6 [Black])
4-8
2.
SATA connectors - ISAS connectors
(7-pin ISAS1, ISAS2, ISAS3, ISAS4 [Gray])
4-9
3.
SAS connectors - PSAS connectors
(7-pin PSAS1, PSAS2, PSAS3, PSAS4 [Light Blue])
4-9
4.
Hard disk activity LED connector (4-pin HDLED1)
4-10
5.
USB connector (10-1 pin USB34, USB56; A-Type USB7)
4-10
6.
VGA connector (10-1 pin VGA_HDR1)
4-11
7.
CPU, front and rear fan connectors
(4-pin CPU_FAN1, CPU_FAN2, FRNT_FAN1, FRNT_FAN2,
FRNT_FAN3, FRNT_FAN4, REAR_FAN1, REAR_FAN2)
4-11
8.
LAN LED connector (LAN34_LED1)
4-12
9.
Serial General Purpose Input/Output connector
(8-1 pin PSGPIO1/2, ISGPIO1, SGPIO1)
4-13
10.
Serial port connectors (10-1 pin COM1/COM2)
4-14
11.
TPM connector (20-1-pin TPM1)
4-14
12.
EATX power connectors
(24-pin EATXPWR1, 8-pin EATX12V1)
4-15
13.
Power Supply SMBUS connector (5-pin PSUSMB1)
4-16
14.
System panel connector (20-1 pin PANEL1)
4-17
15.
Auxiliary panel connector (20-2 pin AUX_PANEL1)
4-18
Internal LEDs
Page
1.
Standby power LED (SB_PWR1)
4-19
2.
BMC LED (BMC_LED1)
4-19
3.
CATT Error LED (CATERR_LED1)
4-20
4.
Location LED (LOCLED2)
4-20
5.
CPU Warning LED (ERR_CPU1/2)
4-21
