14 Chapter 1: Getting started
EN
GL
IS
H
EN
GL
IS
H
EN
GL
IS
H
EN
GL
IS
H
Microphone port (pink). This port connects a microphone.
ASUS Graphics Card (on selected models only). The display output ports on
this optional ASUS Graphics Card may vary with different models.
ASUS WLAN Card (on selected models only). This optional WLAN card allows
your computer to connect to a wireless network.
Expansion slot bracket. Remove the expansion slot bracket when installing an
expansion card.
Refer to the audio configuration table below for the function of the audio ports in a 2, 4,
6, or 8-channel configuration.
Port Headset 2-channel 4-channel 6-channel 8-channel
Light Blue (Rear panel) Line In Rear Speaker Out Rear Speaker Out Rear Speaker Out
Lime (Rear panel) Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink (Rear panel) Mic In Mic In Bass/Center Bass/Center
Lime (Front panel) - - - Side Speaker Out
Audio 2, 4, 6, or 8-channel configuration
