8 connecting the thermal sensor cable – Asus P8B-X User Manual
Page 39
ASUS P8B-X
2-21
2.5.8
Connecting the thermal sensor cable
Follow the steps below to connect the thermal sensor cable to the connector on
your motherboard.
1. Locate the TR1 connector on the
motherboard.
2. Connect the thermal sensor cable to
the connector.
3. Place the other end of the thermal sensor cable to the device you would like
to monitor temperature.
The photos above are for reference only. Follow the main layout in previous
section to locate the TR1 connector on your motherboard.
