xi
P8B-X specifications summary
Processor Support / System Bus 1 x Socket LGA1155
Intel ® Xeon ® E3-1200 Processor Family
Intel ® Core™ i3-2100 Processor Family
Core Logic Intel ® C202 Chipset
Form Factor ATX, 12” x 9.6”
ASUS Features Fan Speed
Control
V
Rack Ready
(Rack and
Pedestal dual
use)
V
ASWM 2.0 V
Memory Total Slots 4 (2 Channels)
Capacity Maximum up to 32GB
Memory Type DDR3 1066/1333 ECC UDIMM
Expansion
Slots
(follow SSI
Location #)
Total PCI/PCI-X/
PCI-E Slots
6
Slot Location 1 1 x PCI 32bit/33 MHz
Slot Location 2 1 x PCI 32bit/33 MHz
Slot Location 3 1 x PCI-E x8 (Gen 2 x4 link)
Slot Location 4 1 x PCI-E x1 (Gen 2 x1 link)
Slot Location 5 1 x PCI-E x1 (Gen 2 x1 link)
Slot Location 6 1 x PCI-E x16 (Gen 2 x16 link)
Storage SATA Controller Intel ® C202:
6 SATA 3Gb/s ports (RAID supported)
- Intel ® Rapid Storage Technology(RST) supports
software RAID 0, 1, 10 & 5(Windows)
Networking LAN 2 x Intel 82574L
Graphic VGA XGI ® Z9s + 64MB VRAM (R1.0x)
ASPEED ® AST1100 + 64MB VRAM (R2.0x)
Onboard I/O
Connectors
TPM Header 1
PSU Connector 24-pin ATX power connector + 8-pin ATX 12V
power connector
USB
Connectors
1 * USB connector (Type A USB socket)
2 * USB pin header (up to 4 devices)
Fan Header 5 x 4pin
Chassis
Intruder
1
Serial Port
Header
1
(continued on the next page)
