34 EeeTop PC ET22 Series
Configuring the audio output
EeeTop PC supports different types of audio configurations. Set up the system using stereo
speakers.
Speaker configurations
Set up the system with the following speaker configurations:
A stereo speaker set is a left-right, two channel speaker system. A multi-channel audio speaker
has a left-right front and left-right rear (surround) channel.
Name Speaker system
2-channel (stereo) Left speaker and right speaker.
Audio jack Headphones/2-channel
Audio Out
Mic In
Connecting to speakers
Refer to the table below for the audio jacks on the left panel and their functions.
For stereo speakers or headphones
Audio jack Description
Connects to stereo speakers or headphones.
