English
3. Pull the cover.
2. Remove the cover screws.
Removing the cover
1. Locate two cover screws.
4. Lift the cover, then set aside.
Removing the front panel assembly
2. Pull the hooks outward to
remove. 1. Locate the front panel
assembly hooks.
5. Lift the expansion card lock to
a 90º-100º angle. 6. Lift the chassis support
bracket, then remove.
