Chapter 2: Setup
2.2
Detaching the arm/stan(for VESA wall
mount)
The detachable stand of the VB178(x)L Series LCD monitor is specially designed
for VESA wall mount.
To detach the arm/stand:
1.
Lower the monitor to its lowest height, and then inset the monitor height
adjustment lock.
2.
Have the front of the monitor face down on a table.
3.
Use a screwdriver to remove the four screws on the VESA cover,the slide out
the arm/base to detach it from the monitor.
•
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
•
Hold the stand of the monitor when you remove the screws.
1
•
The VESA wall mount kit ( 100 mm x 100 mm) is purchased separately.
•
For use only with UL Listed Wall Mount Bracket with minimum weight/load
14.8Kg (Screw size: 4mm x 12 mm)
