Chapter 2: Hardware setup 2-10
Memory population table
For UDIMM, RDIMM and LRDIMM (Single Rank, Dual Ranks, Quad rank)
CPU1 Configuration
A2 A1 B2 B1 C2 C1 D2 D1
1 DIMMs P
2 DIMMs P P
4 DIMMs P P P P
8 DIMMs P P P P P P P P
CPU1 + CPU2 Configuration
A2 A1 B2 B1 C2 C1 D2 D1 E2 E1 F2 F1 G2 G1 H2 H1
2 DIMMs P P
4 DIMMs P P P P
6 DIMMs P P P P P P
8 DIMMs P P P P P P P P
10 DIMMs P P P P P P P P P P
12 DIMMs P P P P P P P P P P P P
14 DIMMs P P P P P P P P P P P P P P
16 DIMMs P P P P P P P P P P P P P P P P
CPU1 + CPU2 + CPU3 + CPU4 Configuration
A2 A1 B2 B1 C2 C1 D2 D1 E2 E1 F2 F1 G2 G1 H2 H1
4 DIMMs P P
8 DIMMs P P P P
12 DIMMs P P P P P P
16 DIMMs P P P P P P P P
20 DIMMs P P P P P P P P P P
24 DIMMs P P P P P P P P P P P P
28 DIMMs P P P P P P P P P P P P P P
32 DIMMs P P P P P P P P P P P P P P P P
CPU1 + CPU2 + CPU3 + CPU4 Configuration
I2 I1 J2 J1 K2 K1 L2 L1 M2 M1 N2 N1 O2 O1 P2 P1
4 DIMMs P P
8 DIMMs P P P P
12 DIMMs P P P P P P
16 DIMMs P P P P P P P P
20 DIMMs P P P P P P P P P P
24 DIMMs P P P P P P P P P P P P
28 DIMMs P P P P P P P P P P P P P P
32 DIMMs P P P P P P P P P P P P P P P P
2.3.2 Memory Configurations
You may install 1GB/2GB/4GB/8GB/16GB/32GB Registerd or 1GB/2GB/4GB/8GB
Unbuffered with ECC/Non-ECC DDR3 DIMMs into the DIMM sockets using the
memory configurations in this section.
