xiii
Z9NA-D6 series specifications summary
Model Name Z9NA-D6 Z9NA-D6C
Storage SATA Controller Intel® C602-A:
4 SATA 3Gb/s ports; 2 SATA
6Gb/s ports
Intel® RSTe (for Windows only)
(Support software RAID 0, 1, 10 &
5)
LSI® MegaRAID (for Linux/
Windows)
(Support software RAID 0, 1, 10)
4 SATA 3Gb/s ports
Intel® RSTe (for Windows only)
(Support software RAID 0, 1, 10 &
5 for all SATA ports)
Intel® C602-A:
4 SATA 3Gb/s ports; 2 SATA
6Gb/s ports
Intel® RSTe (for Windows
only)
(Support software RAID 0, 1,
10 & 5)
SAS Controller Optional kits:
ASUS PIKE 2008 8-port SAS 6G
RAID card
ASUS PIKE 2008/IMR 8-port SAS
6G RAID card
ASUS PIKE 2108 8-port SAS 6G
HW RAID card
-
Networking LAN 2 * Intel 82574L
Graphic VGA Aspeed AST2300 with 16MB
VRAM
Aspeed AST1300 with 64MB
VRAM
Onboard I/O
Connectors
TPM header 1
PSU Connector 24-pin ATX power connector + 8-pin ATX 12V
(Support Both ATX & SSI Power Supply)**
Device Power
Connector
4-pin power connector
Management
Connector
Onboard socket for optional
management card
USB Connectors 1 * USB connector (Type A USB socket)
2 * USB pin header (up to 4 devices)
Fan Header 8 * 4pin
SMBus 2
Chassis Intruder 1
Front LAN LED 2
Serial Port Header 1
Rear I/O
Connectors
External Serial Port 1
External USB Port 4
VGA Port 1
RJ-45 2
PS/2 KB/Mouse 1
(continued on the next page)
