ASUS Essentio Desktop PC 9
English
Knowing your Desktop PC
Front / Rear panel features
Front (Close) Front (Open) Rear
No. Button/LED Description
1. Optical drive bay cover.
2. Optical drive eject button.
3. Open the front panel cover.
4. Front panel cover.
5.
Time display and IR (for some models
only).
6. Hard disk drive LED.
7. Power button (touch-sensitive).
continued on the next page
*The gray areas contain front/rear panel ports.These ports The gray areas contain front/rear panel ports. These ports
and their locations may vary, depending on the model of your
system.
REAR S P K
LIN
E IN FR ON
T MIC IN
SIDE S P K C T
R
B A SS
1
5
4
2
7
6
3
8
10
9
12
11
17
13
14 15
16
