2-1 ASUS LCD Monitor VH238H Series
2.1 Detaching the arm/stand
(for VESA wall mount)
The detachable stand of the VH238H Series LCD monitor is specially designed for
VESA wall mount.
To detach the arm/stand:
1. Remove the arm cover.
2. Have the front of the monitor face down on a table.
3. Use a screwdriver to remove the three screws on the stand of the monitor as
the below drawing shows.
4. Detach the arm from the monitor.
• We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
• Hold the stand of the monitor when you remove the screws.
• The VESA wall mount kit ( 100 x 100 mm) is purchased separately.
• Use only the UL Listed Wall Mount Bracket with minimum weight/load
19.2 Kg (Screw size: M4 x 12 mm).
