Page 35

2-17

ASUS ESC500 G2

3. Insert the drive into the 5.25-inch

drive bay and carefully push the

drive into the bay until its screw

holes align with the holes on the

bay.

2.6.2

Installing 5.25-inch drives

To install 5.25-inch drives

4. Push in the bay locks to secure the

optical drive

1. Select the drive bay you intend to

use and remove the drive slot plate

cover.

2. Release the bay locks.
