2-1
ASUS VW22A LCD Monitor
2.1
Assembling the monitor base
To assemble the monitor base:
1. Have the front of the monitor face down on a table.
2. Connect the base with the arm according to the drawing below. A click shows
that the base has been connected successfuly.
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
2.2
Adjusting the monitor
• For optimal viewing, we recommend that you look at the full face of the
monitor, then adjust the monitor to the angle that is most comfortable for you.
• Hold the stand to prevent the monitor from falling when you change its angle.
• The recommended adjusting angle is
-5˚ to
+20˚
.
It is normal that the monitor slightly shakes while you adjust the viewing angle.
-5˚~20˚
˚~20˚
~20˚˚
