ASUS TS100-E8-PI4
3-3
Layout contents
Jumpers
Page
1.
Clear RTC RAM (CLRTC1)
3-4
2.
VGA controller setting (3-pin VGA_SW1)
3-5
3.
LAN controller setting
(3-pin LAN_SW1, LAN_SW2,)
3-5
4.
Intel
®
C222 SATA port S/W RAID setting (3-pin RAID_SEL1)
3-6
5.
ME firmware force recovery setting (3-pin ME_RCVR1)
3-6
Internal connectors
Page
1.
Serial ATA 6.0/3.0 Gbps connector
(7-pin SATA 6Gbps 1-2 connector [Light Blue])
(7-pin SATA 3Gbps 3-6 connector [Black])
3-7
2.
Hard disk activity LED connector (4-pin HDLED1)
3-8
3.
USB 2.0 connector
(10-1 pin USB78, 10-1 pin USB1011, A-Type USB9)
3-8
4.
Thermal sensor cable connectors (3-pin TR1)
3-9
5.
CPU, front, and rear fan connectors
(4-pin FRNT_FAN1, REAR_FAN1, CPU_FAN1, FRNT_FAN2,
FRNT_FAN3)
3-9
6.
Serial General Purpose Input/Output connector
(6-1 pin SGPIO1)
3-10
7.
Serial port connectors (10-1 pin COM2)
3-10
8.
Trusted Platform Module connector (20-1 pin TPM1)
3-11
9.
SATA DOM power connector (4-pin PWR3)
3-11
10.
ATX power connectors
(24-pin EATXPWR1, 8-pin EATX12V1)
3-12
11.
System panel connector (20-1 pin PANEL1)
3-13
12.
Auxiliary panel connector (20-2 pin AUX_PANEL1)
3-14
