2-4 Chapter 2: RAID configuration
2.2.1 Creating an array
To create a RAID set:
1. From the utility menu bar, select RAID > Create array.
2. Press . The screen shows the disks you can add to make up
the RAID set. Use the arrow key to select a disk and press or
to include this disk in the array.
3. After you have selected the desired disks, select NEXT to create array.
Marvell BIOS Setup (c) 2008 Marvell Technology Group Ltd.
ENTER/SPACE:Select, ESC:Back/Exit
[Selection] [Controller] [ Devices ] [ RAID ]
RAID Config
Create array
Delete array
Wipe out disk
Spare Management
RAID Config
Select free disks to create
Port Disk Name Size Max Speed Status
0 SAS : ST3146855SS 139.9GB SAS 3.0 FREE
1 SAS : ST3146855SS 139.9GB SAS 3.0 FREE
2 SAS : ST3146855SS 139.9GB SAS 3.0 FREE
3 SAS : ST3146855SS 139.9GB SAS 3.0 FREE
4 SAS : ST3146855SS 139.9GB SAS 3.0 FREE
5 SAS : ST3146855SS 139.9GB SAS 3.0 FREE
6 SAS : ST3146855SS 139.9GB SAS 3.0 FREE
7 SAS : ST3146855SS 139.9GB SAS 3.0 FREE
NEXT
Marvell BIOS Setup (c) 2008 Marvell Technology Group Ltd.
ENTER/SPACE:Select, ESC:Back/Exit
[Selection] [Controller] [ Devices ] [ RAID ]
