Layout Features
1 External Antenna port
Connects to an external antenna for better signal performance (the external
antenna is optional)
2 Micro SD Slot Insert the external Micro SD memory card to this slot
3 Sleep Mode Button Press to turn on the device, or to enter into sleep mode
4 Charging LED Red- charging, Yellow- full charged
5 Bluetooth LED When function turning on, it's lighting Blue
6 Light Sensor Automatically adjusts the backlight according to the light in the environment
7 Audio Jack Uses to connect headsets or two-channel speakers
8 Mini USB Connects to other devices through a Mini USB cable
9 Speaker Allows you to listen to music, the navigation voice, and system warning
10 Battery Battery cover
11 Reset Push to perform reset function
12 Main Power switch Turns the main power on/off
1
3
4
5
6
7
8
9
11
1
10
