Page 15

1..

USB.2.0.ports.1.~.4. These 4-pin Universal Serial Bus (USB) ports are available for

connecting USB .0 devices.

2..

HDMI.port..This port is for a High-Definition Multimedia Interface (HDMI) connector,

and is HDCP compliant allowing playback of HD DVD, Blu-Ray and other protected

content.

3..

DVI-D.port..This port is for any DVI-D compatible device. DVI-D can’t be converted to

output RGB Signal to CRT and isn’t compatible with DVI-I.

4..

USB.3.0.ports.1.and.2. These two 9-pin Universal Serial Bus (USB) ports are

available for connecting USB .0/.0 devices.

• DO NOT connect a keyboard / mouse to any USB .0 port when installing Windows

operating system.

• Due to USB .0 controller limitation, USB .0 devices can only be used under Windows

OS environment and after the USB .0 driver installation.

Audio 2, 4, 6, or 8-channel configuration

Refer to the audio configuration table below for the function of the audio ports in 2, 4, 6, or

8-channel configuration.

Port

Headset.2-channel

4-channel

6-channel

8-channel

Light Blue (Rear panel)

Line In

Rear Speaker Out Rear Speaker Out

Rear Speaker Out

Lime (Rear panel)

Line Out

Front Speaker Out Front Speaker Out Front Speaker Out

Pink (Rear panel)

Mic In

Bass/Center

Lime (Front panel)

–

Side Speaker Out

To configure an 8-channel audio output:
Use a chassis with HD audio module in the front panel to support 8-channel audio output.

• USB .0 devices can only be used as data storage only.
• We strongly recommend that you connect USB .0 devices to USB .0 ports for faster

and better performance for your USB .0 devices.

5..

Microphone.port.(pink). This port connects a microphone.

Line.Out.port.(lime). This port connects a headphone or a speaker. In 4-channel, 6-

channel, and 8-channel configurations, the function of this port becomes Front Speaker

Out.

7..

Line.In.port.(light.blue). This port connects the tape, CD, DVD player, or other audio

sources.

8..

Expansion.slot..This slot is reserved for an expansion card.

9..

LAN.(RJ-45).port. This port allows gigabit connection to a Local Area Network (LAN)

through a network hub. Refer to the table below for the LAN port LED indications.
