10. Expansion slot brackets.
Expansion slot brackets. Remove the expansion slot bracket when installing an
expansion card.
11. Voltage selector. Use this switch to select the appropriate system input voltage
according to the voltage supply in your area. If the voltage supply in your area is 100-
17V, set the switch to 115V. If the voltage supply in your area is 00-40V, set the
switch to 0V.
7.
Microphone port (pink).
Microphone port (pink). This port connects to a microphone.
8.
Line Out port (lime).
Line Out port (lime). This port connects to a headphone or speaker. In a 4, 6, or
8-channel configuration, the function of this port becomes Front Speaker Out.
9.
Line In port (light blue).
Line In port (light blue). This port connects to a tape, CD, DVD player, or other audio
sources.
Audio 2, 4, or 6-channel configuration
Refer to the audio configuration table below for the function of the audio ports in a 2, 4, or
6-channel configuration.
DO NOT block the air vents on the chassis. Always provide proper ventilation for your
computer.
12. Air vents. These vents allow air ventilation.
1. Power connector. Plug the power cord to this connector.
14. LAN (R�-45) port.
LAN (R�-45) port. This port allows Gigabit connection to a Local Area Network (LAN)
through a network hub.
LAN port LED indications
Activity/Link LED Speed LED
Status
Description
Status
Description
OFF
No link
OFF
10Mbps connection
ORANGE
Linked
ORANGE
100Mbps connection
BLINKING
Data activity
GREEN
1Gbps connection
LAN port
SPEED
LED
ACT/LINK
LED
15. VGA port.
VGA port. This port is for VGA-compatible devices such as a VGA monitor.
16. Serial port (optional). This COM1 port is for pointing devices or other serial devices.
17. Parallel Port (optional). This port connects a parallel printer, a scanner, or other
devices.
Port
Headset 2-channel
4-channel
6-channel
Light Blue)
Line In
Rear Speaker Out
Rear Speaker Out
Lime
Line Out
Front Speaker Out
Front Speaker Out
Pink
Mic In
Mic In
Bass/Center
0
