xii
Z9NR-D12 specifications summary
Model Name Z9NR-D12
Processor Support / System Bus 2 x Socket LGA 1356
Intel® Xeon® processor E5-2400 product family
QPI 6.4/ 7.2/ 8.0 GT/s
Core Logic Intel ® C602-A PCH
Form Factor EEB, 12” x 13”
ASUS Features Fan Speed Control V
Rack Optimized
(Dedicated for
Rack)
V
ASWM Enterprise V
Memory Total Slots 12 (3 Channels per CPU, 6 DIMM per CPU)
Voltage 1.5V/ 1.35V
Capacity Maximum up to 384GB
Memory Type DDR3 800/1066/1333/1600 RDIMM
DDR3 1066/1333 ECC UDIMM/ Non-ECC UDIMM
DDR3 1066/1333 LR-DIMM
Memory Size 1GB, 2GB, 4GB, 8GB, 16GB, 32GB* (RDIMM)
1GB, 2GB, 4GB, 8GB* (UDIMM)
8GB, 16GB, 32GB* (LRDIMM)
Expansion Slots Total PCI/PCI-X/
PCI-E Slots
7
PCIE 1 1 x PCI-E x8 (X4 Gen3 link, White, from CPU1)
PCIE 2 1 x PCI-E x16 (X16 Gen3 link, White, from CPU1)
PCIE 3 1 x PCI-E x8 (X8 Gen3 link, Black, from CPU2)
PCIE 4 1 x PCI-E x8 (X8 Gen3 link, Black, from CPU2)
PCIE 5 1 x PCI-E x8 (X8 Gen3 link, Black, from CPU2)
PCIE 6 1 x PCI-E x4 (X2 Gen2 link, White, from PCH)
PCIE 7 1 x PCI-E x4 (X1 Gen2 link, White, from PCH)
Additional Slot 1 1 x PIKE-E x8 (x4 Gen3 link, White, from CPU1)
Storage SATA Controller Intel ® C602-A:
2 SATA 6Gb/s ports; 4 SATA 3Gb/s ports
Intel ® RSTe (for Windows only)
(Support software RAID 0, 1, 10 & 5)
LSI ® MegaRAID (for Linux/Windows)
(Support software RAID 0, 1, 10)
4 SATA 3Gb/s ports
Intel ® RSTe (for Windows only)
(Support software RAID 0, 1, 10 & 5 for all SATA ports)
SAS Controller Optional kits:
ASUS PIKE 2008 8-port SAS 6G RAID card
ASUS PIKE 2008/IMR 8-port SAS 6G RAID card
ASUS PIKE 2108 8-port SAS 6G HW RAID card
Networking LAN 4 * Intel 82574L + 1 Management Port
Graphic VGA ASPEED ® AST2300 + 16MB
(continued on the next page)
