4-42 Chapter 4: BIOS setup
4.8 Monitor menu
The Monitor menu displays the system temperature/power status, and allows you
to change the fan settings.
Scroll down to display the following items:
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Server Mgmt Event Logs Boot Monitor Security Tool Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
CPU1 Temperature N/A
CPU2 Temperature N/A
TR1 Temperature N/A
TR2 Temperature N/A
CPU FAN1 Speed N/A
CPU FAN2 Speed N/A
FRNT FAN1 Speed N/A
FRNT FAN2 Speed N/A
FRNT FAN3 Speed N/A
FRNT FAN4 Speed N/A
REAR FAN1 Speed N/A
REAR FAN2 Speed N/A
+VTT_CPU N/A
VCORE1 N/A
VCORE2 N/A
+VDDQ_CPU1 N/A
+VDDQ_CPU2 N/A
+5VSB N/A
+5V N/A
+12V N/A
+3.3V N/A
VBAT N/A
+3.3VSB N/A
FAN Speed Control [Generic Mode]
CPU 1/2; TR1 1/2 Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the CPU and
motherboard component temperatures.
CPU FAN1/2 Speed; FRNT FAN1–4 Speed; REAR FAN1/2 Speed
[xxxx RPM] or [N/A]
The onboard hardware monitor automatically detects and displays the speed of
CPU fans, front fans, and rear fan in rotations per minute (RPM). If the fan is not
connected to the motherboard, the field shows N/A.
+VTT_CPU Voltage, VCORE1/2 Voltage, +VDDQ_CPU1 Voltage,
+VDDQ_CPU2 Voltage, +5VSB Voltage, +5V Voltage, +12V Voltage,
+3.3V Voltage, VBAT Voltage, +3.3VSB Voltage
The onboard hardware monitor automatically detects the voltage output through
the onboard voltage regulators.
