Using the Notebook PC
Inserting a PC Card (PCMCIA)
1. If there is a PC Card socket protector, remove it using the “Removing a PC Card” instructions
below.
2. Insert the PC card with the connector side first and label side up. Standard PC cards will be flush
with the Notebook PC when fully inserted.
3. Carefully connect any cables or adapters needed by the PC card. Usually connectors can only be
inserted in one orientation. Look for a sticker, icon, or marking on one side of the connector repre-
senting the top side.
1. Press in the toggle eject button and release.
The recessed spring loaded toggle button will
extend when pushed in and released.
2. Press the extended button again to eject the PC
Card. Carefully pull the ejected PC card out of
the socket.
Removing a PC Card (PCMCIA)
To remove the PC card, first remove all cables or adapters attached to the PC card, then double-click the
PC card icon on the Windows taskbar and stop the PC card you want to remove.
5
3
4
1
Be sure the PC card is
level when inserting.
2
