4 - 8 4 - 8 4 - 8 4 - 8 4 - 8 C h a p t e r 4 : M o t h e r b o a r d i n f o C h a p t e r 4 : M o t h e r b o a r d i n f o C h a p t e r 4 : M o t h e r b o a r d i n f o C h a p t e r 4 : M o t h e r b o a r d i n f o C h a p t e r 4 : M o t h e r b o a r d i n f o
8 . 8 . 8 . 8 . 8 . S e r i a l A T A c o n n e c t o r ( 7 - p i n S A T A 1 ) S e r i a l A T A c o n n e c t o r ( 7 - p i n S A T A 1 ) S e r i a l A T A c o n n e c t o r ( 7 - p i n S A T A 1 ) S e r i a l A T A c o n n e c t o r ( 7 - p i n S A T A 1 ) S e r i a l A T A c o n n e c t o r ( 7 - p i n S A T A 1 )
This connector is for the Serial ATA signal cables for a Serial ATA hard
disk drive.
You must install Windows ® 2000 Service Pack 4 or the Windows ® XP
Service Pack 1 before using a Serial ATA hard disk drive.
SATA connector
SATA1
GND
RSATA_TXP1
RSATA_TXN1
GND
RSATA_RXN1
RSATA_RXP1
GND
