24
2
Knowing the Parts
1 2 3 4 6 7 8
Serial Port
The 9-pin D-sub serial port supports native serial devices such as a serial drawing
tablets, serial mouse, or serial modem. Serial devices have been slowly replaced by
USB devices.
2
3
1
4
PS/2 Port
The PS/2 port is for connection to either an external PS/2 mouse or an external
PS/2 keyboard.
Power (DC) Input (Power Station)
The supplied power adapter converts AC power to DC power for use with
this jack. Power supplied through this jack supplies power to the power
station, Notebook PC, and charges the Notebook PC’s battery pack. To
prevent damage to the power station, Notebook PC, and battery pack,
always use the supplied power adapter. CAUTION: MAY BECOME WARM TO HOT WHEN IN USE.
BE SURE NOT TO COVER THE ADAPTER AND KEEP IT AWAY FROM YOUR BODY.
The power station has
its own power adapter.
Power Station (optional)
Rear Side
2.0
USB Port (2.0/1.1)
The USB (Universal Serial Bus) port is compatible with USB 2.0 or USB 1.1 devices
such as keyboards, pointing devices, cameras, hard disk drives, printers, and scanners
connected in a series up to 12Mbits/sec (USB 1.1) and 480Mbits/sec (USB 2.0). USB
allows many devices to run simultaneously on a single computer, with some peripherals
acting as additional plug-in sites or hubs. USB supports hot-swapping of devices so that
most peripherals can be connected or disconnected without restarting the computer.
LAN Port
The RJ-45 LAN port with eight pins is larger than the RJ-11 modem port and supports a
standard Ethernet cable for connection to a local network. The built-in connector allows
convenient use without additional adapters.
(continued on next page)
