Setting up MyPal
When using the cradle, position the device
with the cradle connector aligned to the
device connector on the cradle.
Connect the AC adapter cable to the
connector at the back of the cradle.
Connect the power plug to a
grounded power source.
Charging status LED
Blinks green when battery is charging
Steady green when battery is fully charged
Connect the AC adapter cable to the connector at the
bottom of the device.
Connect the power plug to a grounded power source.
Note that the charging status LED blinks green.
1
2
a
2
b
Device connector
Cradle connector/ Sync cable connector
