Getting to know MyPal
Left side Right side
Enter button
Back button
Infrared (IR) port
Reset switch
Next button
Power connector
Battery latch
Cradle connector /
Sync cable connector Built-in microphone
CF card slot CF card eject button
Stylus Headphone jack
SD card slot
Front features Back features
Side features
Top features Bottom features
NOTE: The external
(main) battery is not
installed in the device
when shipped. To install
the battery, position it as
shown then slide upward
until it fits in place. To
secure the battery, use
the stylus to slide the
battery latch hole toward
the locked icon.
External battery
LCD touch screen
Navigation button
Tasks button
Contacts button
ASUS Launcher
button
Calendar button
Speaker
Power button/
Backlight button
Wireless antenna
Bluetooth/Wireless LAN LED
Power LED
