3-8 Chapter 3: RAID configuration
3.3 Marvell RAID BIOS setup utility
You can also create a RAID 0, RAID 1 or RAID 10 array using two SATA hard disk
drives using the Marvell RAID BIOS Setup.
To enter the Marvell RAID BIOS utility, press + during POST.
All exisiting data on the hard disk drives will be erased when creating or deleting
a RAID array. Ensure that you have back up all your data in your hard disk drives
before making any change to the drive status.
Marvell BIOS Setup (c) 2011 Marvell Technology Group Ltd.
Topology
Information
Help
Marvell RAID on chip controller.
ENTER: Operation F10: Exit/Save ESC: Return
HBA 0: Marvell 0
├ Virtual Disks
└ Free Physical Disks
├ PD 0: ST3160812AS
└ PD 8: ST3160812AS
Vendor ID : 1B4B
Device ID : 9130
Revision ID : B1
BIOS Version : 1.0.0.1028
Firmware Version: 2.2.0.1105
PCIe Speed Rate : 5.0Gbps
Configure SATA as: AHCI Mode
▶ ▶
3.3.1 Create a RAID Array
1. Move the selection bar to HBA 0: Marvell 0 and press .
2. Select Configuration Wizard and press .
3. Press to select the hard drives to be included in the RAID array. An
asterisk (*) appears in front of the selected hard drive. After selecting all the
drives needed for the RAID array, press to continue.
Marvell BIOS Setup (c) 2011 Marvell Technology Group Ltd.
Configure->Select free disks
Help
Use space bar to select the free disks to be used in the array.
ENTER: Operation SPACE: Select F10: Exit/Save ESC: Return
HBA 0: Marvell 0
├ Virtual Disks
└ Free Physical Disks
* ├ PD 0: ST3160812AS
└ PD 8: ST3160812AS
Port ID : 0
PD ID : 0
Type : SATA PD
Status : Unconfigured
Size : 152626MB
Feature Support : MCQ 3G 48Bits
Current Speed : 3G
Model : ST3160812AS
Serial : 9LS0F4HL
FW Version : 3.AAE
▶ ▶
