2-2 Chapter 2: Hardware information
2.2 Motherboard layout
24.9cm (9.8in)
30.5cm (12in)
PC-DL
Accelerated Graphics Port (AGP8X1)
CHA
F
AN1
FLOPPY1
4Mbit Flash BIOS
SEC_IDE1
PANEL1
SYS_FAN2
DDR DIMM1 (72 bit, 184-pin module)
Intel
82547EI
Gigabit
Ethernet
Super
I/O
IEEE1394_1
GAME1
SB_PWR1
USB1
Intel
82875P
(Canterwood)
Intel I/O
Controller
Hub
(ICH5R)
mPGA
604
mPGA
604
DDR DIMM2 (72 bit, 184-pin module) DDR DIMM3 (72 bit, 184-pin module) DDR DIMM4 (72 bit, 184-pin module)
PCI1
USB2.0
T: USB1
B: USB2
Top:
RJ-45
T:USB4
B:USB3
Bottom:
1394
Top:
Below:Mic In
Center:Line Out
Top:Line In
PCI2
PCI3
PCI4
PCI5
PS/2KBMS
T: Mouse
B: Keyboard
COM1
P
ARALLEL
PORT
COM2
CR2032 3V
Lithium Cell
CMOS Power
PRI_IDE1
CON12V
KBPWR1
CPU_FAN2
CPU_FAN1
USBPW1
USBPW2
FP_AUDIO1
USB2
SYS_FAN1
MODEM1
Audio
Codec
SATA1
AGP_WARN1
PROMISE PDC20378
RAID
Controller
Speech
Controller
TI
TSB43AB22A
SPDIF_OUT
CD1
AUX1
SATA2
SATA_RAID1 SATA_RAID2
J1
CHASSIS1
CLR
TC1
J4
USBPW3
USBPW4
SMB1
SSI_POWER
CPU1
CPU2
LED1
