1. PS/2 mouse port (green). This port is for a PS/ mouse.
2. PS/2 keyboard port (purple). This port is for a PS/ keyboard.
3. DVI�D port. DVI�D port. This port is for any DVI-D compatible device and is HDCP compliant
allowing playback of HD DVD, Blu-ray, and other protected content.
4. USB 3.0 ports. These Universal Serial Bus 3.0 (USB 3.0) ports connect to USB 3.0
devices such as a mouse, printer, scanner, camera, PDA, and others.
• DO NOT connect a keyboard / mouse to any USB 3.0 port when installing Windows ®
operating system.
• Due to USB 3.0 controller limitation, USB 3.0 devices can only be used under Windows ®
OS environment and after the USB 3.0 driver installation.
• USB 3.0 devices can only be used as data storage only.
• We strongly recommend that you connect USB 3.0 devices to USB 3.0 ports for faster
and better performance for your USB 3.0 devices.
2
3
BP6335(SD560)
13
14
1
6 7 8
9
11
11
12 10
14. Air vents. Air vents. These vents allow air ventilation.
DO NOT block the air vents on the chassis. Always provide proper ventilation for your
computer.
15. VGA port. VGA port. This port is for VGA-compatible devices such as a VGA monitor.
Rear USB 3.0 port 2
Rear USB 3.0 port 1
Rear USB 2.0 port 3
Rear USB 2.0 port 4
5
4
EN
GL
IS
H
EN
GL
IS
H
ASUS BM6635(MD560), BM6835, and BP6335(SD560) 19
