Page 16

2-3
ASUS VG278HR Series LCD Monitor
2.3 Detaching the arm (for VESA wall
mount)
The detachable arm of this monitor is specially designed for VESA wall
mount.
To detach the arm:
1. Disconnect power and signal cables.
2. Lower the monitor to its lowest height, and then insert the height
adjustment lock.
3. Carefully put the front of the monitor face down on a flat and clean
table.
4. Use a screwdriver to remove the four screwdrivers on the arm, and
then detach the arm from the monitor.
• We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
• Hold the stand while removing the screws.
• The VESA wall mount kit ( 100 x 100 mm) is purchased separately.
• Use only the UL Listed Wall Mount Bracket with minimum weight/load 33.2kg
(Screw size: M4 x 10 mm).
