12 ASUS NOVA LITE SURF PX10
English
5
6
7
8
LAN port
The eight-pin RJ-45 LAN port supports a standard Ethernet
cable for connection to a local network.
Line in port
Plug an 3.5mm mini-jack stereo audio cable into this jack for
analog audio transfer.
Headphone output jack
The 1/8” stereo headphone jack (3.55mm) is used to
connect the system’s audio out signal to amplified speakers
or headphones. Using this jack automatically disables the
built-in speakers.
Microphone jack
The microphone jack is designed to connect the
microphone used for video conferencing, voice narrations,
or simple audio recordings.
Bottom view
Refer to the diagram below to identify the components on this side
of the system.
9
Docking connector
The optional docking
allows future
capabilities expansion
to your PX10.
9
