1-2
Chapter 1: Product Introduction
1.3 Assembling the monitor base
To assemble the monitor base:
1. Connect the base with the arm of monitor and turn clockwise. A click
indicates that the base has been connected successfully.
2. Adjust the monitor to the angle that is most comfortable for you.
We recommend that you cover the table surface with soft cloth to
prevent damage to the monitor.
2
1
1
Make sure to screw the base to the arm tightly.
1.4 Connecting cables
To connect cables:
Connect the cables you need based on chapter 1.5.2, page1-5.
