Bottom side – Asus D1T User Manual
Page 15
15
Knowing the Parts
2
Bottom Side
Refer to the diagram below to identify the components on the bottom side of the Portable Desktop PC.
WARNING! The bottom of the Portable Desktop PC can get very hot. Be careful when
handling the Portable Desktop PC while it is in operation or recently been in operation.
High temperatures are normal during charging or operation. DO NOT PUT THE
PORTABLE DESKTOP PC ON THE LAP OR OTHER PARTS OF THE BODY TO AVOID
INJURY FROM THE HEAT.
CPU
Compartment
Air Vent &
Cooling Fan
Memory
Compartment
Air Vent
Hard Drive
Compartment
Audio Speaker
Audio Speaker
CD/DVD
ROM
