Welcome, Package contents, Card layout – Asus U3S6 User Manual
Page 5
5
Welcome!
Thank you for buying an ASUS
®
US6 expansion card!
The ASUS US6 expansion card allows you to install two SATA 6G hard disk
drives and two USB .0 devices.
Before you start installing the expansion card, check the items in your package
with the list below.
Package contents
Check your package for the following items.
•
ASUS US6 expansion card
•
x Serial ATA 6.0Gb/s cables
•
Support CD
•
User guide
If any of the above items is damaged or missing, contact your retailer.
Card layout
The illustration below shows the major components of the US6 expansion card.
SATA 6Gb/s
connector 2
SATA 6Gb/s connector 1
PCI Express x4 interface
USB 3.0
connector 1
USB 3.0
connector 2
