Refer to the audio configuration table below for the function of the audio ports in a 2, 4, 6,
or 8-channel configuration.
4.
DisplayPort. This port connects a display monitor or a home-theater system.
5.
DVI-D port. This port is for any DVI-D compatible device and is HDCP compliant
allowing playback of HD DVD, Blu-ray, and other protected content.
6.
USB 3.0 ports, support ASUS USB 3.0 Boost UASP Mode. Bottom port supports
USB BIOS Flashback.
7.
Side Speaker Out port (gray). This port connects to the side speakers in an 8-channel
audio configuration.
8.
Rear Speaker Out port (black).
Rear Speaker Out port (black). This port connects to the rear speakers in a 4, 6, and
8-channel audio configuration.
9.
Center/Subwoofer port (orange). This port connects to the center/subwoofer
speakers.
10. Microphone port (pink).
Microphone port (pink). This port connects to a microphone.
11. Line Out port (lime).
Line Out port (lime). This port connects to a headphone or speaker. In a 4, 6, or
8-channel configuration, the function of this port becomes Front Speaker Out.
12. Line In port (light blue).
Line In port (light blue). This port connects to a tape, CD, DVD player, or other audio
sources.
Audio 2, 4, 6, or 8-channel configuration
Port
Headset
2-channel
4-channel
6-channel
8-channel
Light Blue
Line In
Line In
Line In
Line In
Lime
Line Out
Front Speaker Out
Front Speaker Out
Front Speaker Out
Pink
Mic In
Mic In
Mic In
Mic In
Orange
–
–
Center/Subwoofer
Center/Subwoofer
Black
–
Rear Speaker Out
Rear Speaker Out
Rear Speaker Out
Gray
–
–
–
Side Speaker Out
3.
ASUS Wi-Fi GO! card (Wi-Fi 802.11). Connect the Wi-Fi Ring moving antenna to this
port.
Status
Description
Off
No link
Green
Linked
* Wi-Fi LED indications
ASUS Wi-Fi GO! card automatically sets itself to the country's available Wi-Fi channels.
