Monoblock [USX-45KV.1/65KV.1] Amplifiers
[MLT(Multi-Link Technology) TM Wiring]
from OUTPUT of HEAD UNIT
MASTER
SLAVE
RCA Connection
Power & Speaker Connection
Common Ground
(Not used)
Minimum Impedance: 2 Ω
CONNECTIONS
Impedance: 1~2Ω
+
from REMOTE OUTPUT
of HEAD UNIT
to BATTERY GROUND
Power & Speaker Connection
from OUTPUT of HEAD UNIT
RCA Connection
Monoblock [USX-45KV.1/65KV.1] Amplifiers
[Basic Wiring]
CONNECTIONS
