2
• Use at least 8-gauge wire for power and ground connections
• Use at least 12-gauge wire for speaker connections
• Use at least 16-gauge wire for remote connection
• Mount the amplifier where it can receive the best ventilation
• Use the shortest ground connection to the chassis of the vehicle and make sure that the paint
is removed at the connection point
• Connect the remote input to the remote/antenna output of the head unit
• Mount the fuse holder within 200mm(8”) of the vehicle’s battery. Use a fuse equal to that
specified for your amplifier if a large, single +12V line is run which feeds more than one amplifier
add up all required fuse ratings and use the total rating for the fuse
• Connect the speaker to the amplifier observing the correct phasing. Make sure that none of the
speaker connections can touch the vehicle chassis
• Connect the RCA inputs to the appropriate signal source using only the highest quality RCA
cables
• Make sure that the RCA and speaker cables do not run parallel to the +12V wiring
INSTALLATION
• High-current Matched MOSFET devices
• Magnetic Induction Drive Power Supply
—Drive pulse down to 9 volts input (45KV.1/65KV.1)
• 35 nanosecond Switching Diodes
• All metallized, high temperature, low ESR capacitors
• 1008 amps(45KV.1) / 2016 amps(65KV.1) of power devices
• High capacity power transformer
• Multiple Bypass capacitors on incoming 12 volt supply
• Time delay turn on
• Thermal, current, and reverse polarity protection
• New stability filter design for reduction in noise
POWER SUPPLY
• Class DE technology utilizing our Elevated Efficiency Platform (45KV.1/65KV.1)
• Output stages utilize high-current Matched MOSFET devices
• High speed, audio-grade components in all low level stages
• Platinum plated RCA inputs and connectors
• Wide range of sensitivity accepts signal from any head unit including speaker leads
• 24 dB/octave Subsonic Filter (45KV.1/65KV.1) / 24 dB/octave Electronic Crossover
• Auto bridge feature / Short circuit protection
• 240 amps(45KV.1) / 360 amps(65KV.1) of output devices
AMPLIFIERS
FEATURES
9
SPECIFICATIONS
