GB
18
Description of the
appliance
Overall view
* Only available on certain models.
• The INDICATOR LIGHT FOR ELECTRIC
HOTPLATES / COOKTOP BROILER / CERAMIC
GLASS MODULE *
switches on whenever the
selector knob is moved from the ‘off’ position.
• GAS BURNERS differ in size and power. Use the
diameter of the cookware to choose the most
appropriate burner to cook with.
• Control Knobs for GAS BURNERS and ELECTRIC
HOTPLATES / COOKTOP BROILER / CERAMIC
GLASS MODULE *
adjust the power or the size of
the flame.
• GAS BURNER ignition * enables a specific burner
to be lit automatically.
• SAFETY DEVICE * stops the gas flow if the flame
is accidentally extinguished.
SAFETY
DEVICES *
Ignition for
GAS BURNERS *
Indicator Light for
ELECTRIC HOTPLATES *
Control Knobs for
GAS BURNERS and
ELECTRIC HOTPLATES *
Support Grid for
COOKWARE
1
2
3 4
5
6
GAS BURNERS
Ignition Button for
GAS BURNERS *
ELECTRIC HOT PLATES *
/
COOKTOP BROILER *
/
CERAMIC GLASS
MODULE *
! The stainless steel grease pan and the cast-iron grill, located in the burner and grate packing box, must be installed,
respectively, below and above the electric heating element so that the element is enclosed between the two.
