Zanussi ZTH485 - Manual (Page 26)

adjustable height 1.5 cm
the appliance weight 52 kg
maximum load volume 7 kg
voltage 220-230 V
necessary fuse 6 A
total power 1050 W
energy efficiency class A
energy consumption kWh/cycle 1) 1,85 kWh
annual energy consumption 124,2 kWh
type of use Domestic
permitted ambient temperature + 5°C to + 35°C
1) 7 kg of cotton, centrifuged at 1000 rpm with reference to EN 61121
Machine settings
Setting Implementation
BUZZER permanent off 1. Turn the programme selector to any programme.
2. Press simultaneously the INTENSIVE and LONG ANTICREASE buttons and
hold down for approx. 5 seconds.
3. The buzzer is by default always off.
Water hardness
Water contains, a variable quantity
of limestone and mineral salts of
which quantities vary according to
geographical locations thus vary-
ing its conductivity values.
Relevant variations of the conduc-
tivity of the water compared to
those prefixed by the factory could
slightly influence the residual hu-
midity of the laundry at the end of
the cycle. Your dryer allows you to
regulate the sensitivity of the dry-
ing sensor based on conductivity
values of the water.
1. Turn the programme selector to any programme.
2. Press simultaneously the LONG ANTICREASE and START/PAUSE buttons
and hold down for approx. 5 seconds. The current setting is on the display:
–
low conductivity <300 micro S/cm
– medium conductivity 300-600 micro S/cm
– high conductivity >600 micro S/cm
3. Press the START/PAUSE button sequentially until you set desired level.
4. To memorize setting press simultaneously the the LONG ANTICREASE and
START/PAUSE buttons or turn knob to O off position
Hints for test institutes
Parameters possible to checked by the Test Institutes:
• Energy consumption (corrected with final humidity)
during the cupboard dry cotton cycle with nominal
load.
• Energy consumption (corrected with final humidity)
during the cupboard dry cotton cycle with half load.
• Final humidity (during cupboard dry cotton, iron dry
cotton and cupboard dry easy care)
26
