Dayton Audio CE38M-8 1-1 User Manual
Impedance, 1 khz fs, Qms qes qts mms
Last Revised: 2/26/2014
CE38M-8
1-1/2" Mini Speaker 8 Ohm
Impedance (
Ω
)
Re (
Ω
)
Le (
mH
) @ 1 kHz
Fs (
Hz
)
Qms
Qes
Qts
Mms (
g
)
Cms (
mm/N
)
Sd (
cm
2
)
Vd (
cm
3
)
BL (
Tm
)
V
as
(
liters
)
X
max
(
mm
)
VC Diameter (
mm
)
SPL (
dB 1W/1m
)
RMS Power Handling (
W
)
Usable Frequency Range (
Hz
)
• Lightweight Mylar diaphragm
• Extended frequency range
• Neodymium magnet structure
• Injection-molded nonmetallic frame
• Suitable for low power applications
• 8 ohm impedance compatible with
most amplifiers
8
7.72
0.172
191.8
1.59
4.45
1.17
0.07
9.68
4.91
0.05
0.39
0.33
0.1
12.5
75
0.25
190-20,000
50
45
40
35
30
25
20
15
10
5
0
Ohms
180°
90°
0
deg
-90°
-180°
1
2
5
10
20
50
100
200
500
1kHz
2k
5k
10k
20k
1.0.1
OmniMic
20
0
0
2
0
0
1
0
5
k
2
k
1
0
0
5
k
0
2
k
0
1
k
5
Frequency Response -- frequency [Hz]
[d
B
S
P
L
]
95
90
85
80
75
70
65
60
55
50
45
0.8
Ш42.0
7.6
Ш39.8
1.0
40°
1.8
Ш7.2
Ш38.9
Note: Frequency response measured at 0.5m using 1.4V stimulus (0.25W)
