A CONNECTOR TYPES AND PIN DEFINITIONS
Appendices
There are three interfaces in the Sirius: RS-232, Key Board Wedge and USB
(plus power). The various pin definitions (depending on the used type of
interface) are given below. The connector type is RJ-48, 10 pins.
IMPORTANT
Various interface cables are available, depending on the kind of
PC/POS system you use. See Chapter 2.5. Contact your supplier
for availability. In case you need a special interface cable, you can
use the information below.
Pin definitions for multi interface.
Connector: RJ-48, 10 pins.
Multiple Interface
RS-232 KBW USB
Pin Description Description Description Remark
1
2
3
4
5
6
7
8
9
10
-
CTS
RxD
TxD
RTS
Ground
+5.2V
D-Power
-
-
-
PC-Clock
PC-Data
KB-Data
KB-Clock
Ground
+5.2 V
D-Power
IFID: connect
to Pin 6
-
IFID
-
-
IFID: connect
to Pin 1
-
Ground
+5.2 V
D-Power
D +
D -
IFID=InterFace ID
IFID=InterFace ID
Ground
5.2Vdc DC input
to power scanner *
8-16Vdc DC input
to power scanner *
IFID=InterFace ID
D + = USB data
D - = USB data
* The Sirius only requires one single DC input.
