82
Up Down
E. Technical Specifications
Physical Characteristics: Scanner
Scanner Weight Approx. 235g (include batteries)
Charger Weight Approx. 135g (include adaptor)
Material ABS Plastic
Dimension 82.9 mm(L) x 75.0 mm(W) x 171.3 mm(H)
Physical Characteristics: Bluetooth Cradle
Weight Approx 150 g
Material ABS Plastic
Connector RJ 45C 10Pins
Dimension 130.6 mm(L) x 112.2 mm(W) x 84.6 mm(H)
Operational
Light Source Visible Red light 650nm Laser
Sensor Photo Diode
Processor Type ARM Cortex™-M3, 32-bit
Operating Freq. 8 MHz
Scan Speed 500 scans/sec ±10%
Depth of Field Up to 300mm@20mil/0.5mm, PCS90%
Print Contrast
Ratio PCS45%@5mil/0.127mm
Minimum
Resolution 4mil/0.1mm@PCS90%, Code 39
Reading Angle Test Conditions:PCS90%
Code 39, 10mil/0.25mm
Pitch Angle
±5°~60° (±5°)
Skew Angle
±5°~60° (±5°)
Ambient Light 10,000 Lux Max.
