FF 4/2/TETRA/FM/GPS-BBMU
Disguise Antenna for Ford Focus
DESCRIPTION
4-Band mobile antenna with 4 m, 2 m, 70 cm and FM bands.
GPS-antenna for fixed installations.
External antenna whip mounted on the FORD GPS mount.
Full hemispherical coverage.
Built-in high-gain, low-noise amplifier.
Right-Hand Circularly Polarized antenna (RHCP).
DC supply via RF-connector.
Polyethylene-covered flexible whip.
Easily removable whip for car wash.
Matching unit (BBMU) included.
ORDERING DESIGNATIONS
TYPE
PRODUCT NO.
FF 4/2/TETRA/FM/GPS-BBMU
132000107
SPECIFICATIONS FOR WHIP
ELECTRICAL
MODEL
FF 4/2/TETRA/FM/GPS-BBMU
ANTENNA TYPE
Collinear mobile whip antenna
FREQUENCY
4 m: 74.2 - 87.5 MHz
2 m: 167.5 - 174 MHz
70 cm: 380 - 400 MHz
FM band: 93 - 108 MHz (Limited in 88 - 93 MHz)
SWR
74.2 - 77.7 and 84 - 87.5 MHz: < 2.5
167.5 - 169.5 and 172 - 174 MHz: < 2.0
380 - 400 MHz: < 2.0
IMPEDANCE
Nom. 50 Ω
POLARIZATION
Vertical
GAIN
4 m: Approx. -10/-15 dB
2 m: Approx. -10/-15 dB
70 cm: Approx. -5/-10 dB (acc. to EIA RS-329-1)
MAX. POWER
15 W
MECHANICAL
MATERIALS
Glass fibre whip with copper wire winding,
polyethylene-covered.
Black-chromed brass
COLOUR
Black
HEIGHT
660 mm
WEIGHT
102 g
MOUNTING
On standard FORD GPS mount
PROCOM A/S reserve the right to amend specifications
without prior notice.
06/02/12
