Procom DPA 900-2400-...-sma User Manual
Procom Accessories communication

DPA 900/2400/...-SMA
Dual Band Portable Antanna for 900 and 2400 MHz Bands
DESCRIPTION
This antenna makes it possible to operate on 900 and 2400 MHz at the
same time on one antenna.
Flexible antenna element built into an elastic shroud of hard-wearing
and
weather- and shockproof plastics.
Ready-tuned and unity gain on both bands.
Provided with SMA male connector.
Fixed 2400 MHz and 900 MHz Band within 868 - 960 MHz.
ORDERING DESIGNATIONS
TYPE
PRODUCT NO.
DPA 900/2400/...-SMA
140000290
SPECIFICATIONS
ELECTRICAL
MODEL
DPA 900/2400/...-SMA
ANTENNA TYPE
Dual Band portable antenna
FREQUENCY
Models within 868 - 960 MHz
2300 - 2500 MHz
IMPEDANCE
Nom. 50 Ω
POLARIZATION
Vertical
GAIN
0 dB compared to a ¼ λ portable antenna
on the same equpiment
BANDWIDTH
900 MHz : ≥ 80 MHz @ SWR ≤ 2.0
2400 MHz : ≥ 200 MHz @ SWR ≤ 2.0
SWR
900 MHz : < 1.5 @ f. res.
2400 MHz : < 2.0 @ f. res.
MAX. POWER
25 W
MECHANICAL
MATERIALS
Thermoplastic rubber
Cu-nite Brass
COLOUR
Black
TOTAL HEIGHT
Approx. 80 mm
WEIGHT
Approx. 10 g
CONNECTOR
SMA (male)
PROCOM A/S reserve the right to amend specifications
without prior notice.
16/03/11
