Procom DM-fs-1 - Manual

DM FS-1
Foot actuated air pressure PTT switch
DESCRIPTION
Low-profile easy to operate air pump.
Discreet installation.
No wires from the actuator to the electrical circuit.
No leakage current in critical applications.
UL approved.
ORDERING DESIGNATIONS
TYPE NO. PRODUCT NO.
DM FS-1 270000071
SPECIFICATIONS
ELECTRICAL
MODEL DM FS-1
TYPE SPDT Momentary (press-on, release off)
RATING 250 VAC 16 A
MECHANICAL
Air presure for activating the switch 5 psi
AIR PUMP DIAMETER 93 mm
AIR PUMP HEIGHT 16.5 mm
HOSE LENGTH 2 m
WEIGHT 130 g
PROCOM A/S reserve the right to amend specifications
without prior notice.
01/12/11
