DM 6600 F
Goose Neck Hands-Free Microphone
DESCRIPTION
Goose neck microphone for hands-free operation in vehicles.
Mounting on steering column, dash board, window frame etc.
Attractive design.
Uni-directional pattern.
High-sensitivity electret cartridge with amplifier.
Voltage supply 9–15 VDC when connected as shown in the diagram
below.
Supplied with 4 m cable terminated with a 3.5 mm plug.
Wind cap.
ORDERING DESIGNATIONS
TYPE NO. PRODUCT NO.
DM 6600 F 270000038
SPECIFICATIONS
ELECTRICAL
MODEL DM 6600 F
TYPE Goose neck microphone
POLAR PATTERN Uni-directional
IMPEDANCE 1 kΩ
FREQ. RESPONSE Shown in diagram below
SENSITIVITY -44 dB ± 3 dB at 1 kHz rel. 1 V/Pa
CARTRIDGE TYPE Electret
VOLTAGE SUPPLY Nominal: 2 V (Max. 10 V) directly on cartridge
CURRENT CONSUMPTION Approx. 0.5 mA
MECHANICAL
CABLE 4 m 1 wire with shield with 3.5 mm plug
COLOUR Black
TEMP. RANGE Operating : -25° C to + 55° C
Storage : -40° C to + 55° C
MATERIALS Brass, epoxy laquered.
Impact-proof ABS
DIMENSIONS 350 (L) x 12 (D) mm
WEIGHT Approx. 100 g
PROCOM A/S reserve the right to amend specifications
without prior notice.
24/11/11
