FSP 1.5/...-FME
“StraightFlex” Antenna with Universal FME-Connection
System for Portable Equipment in the 200 MHz Band
DESCRIPTION
Highly flexible, polyethylene covered StraightFlex steel wire.
Full size ¼ λ antenna whip.
Highest quality materials in an elegant and slender design.
Delivered factory tuned and tested to ensure minimum SWR and
optimum performance.
Provided with universal FME-connection system for optimum flexibility
and easily exchangeable connectors.
Designed for use with the following of Procoms line of black FME-
connectors (to be ordered separately): BFME-UHF, BFME-BNC, BFME-
TNC, BFME-N, BFME-MUHF, BFME-EBNC, BFME-ETNC and BFME-
EMUHF.
ORDERING DESIGNATIONS
TYPE
PRODUCT NO.
FREQUENCY
FSP 1.5/l-FME
140000151
175 – 200 MHz
FSP 1.5/m-FME
140000152
190 – 215 MHz
FSP 1.5/h-FME
140000150
200 – 225 MHz
SPECIFICATIONS
ELECTRICAL
MODEL
FSP 1.5/...-FME
ANTENNA TYPE
¼ λ antenna for portable equipment
FREQUENCY
175 – 225 MHz covered by three models
IMPEDANCE
Nom. 50 Ω
POLARIZATION
Vertical
GAIN
0 dB (equal to a ¼ λ portable antenna)
BANDWIDTH
≤ 25 MHz @ SWR ≤ 2.5
SWR
< 2 when mounted directly on portable equipment
MAX. POWER
100 W
MECHANICAL
MATERIALS
Polyethylene covered flexible steel wire
Black-chromed brass
COLOUR
Black
TOTAL HEIGHT
Approx. 420 mm (dep. on type)
WEIGHT
Approx. 30 g
CONNECTOR
FME (female) (Exchangeable BFME-connectors
to be ordered separately)
RECOMMENDED BFME-CONNECTORS
(To be ordered separately)
PLEASE NOTE
The FSP 1.5 is also available with SMA male connector and different thread
studs, but in this case with fixed, non-exchangeable connector (not FME-
connection system). Information on these special versions on request.
PROCOM A/S reserve the right to amend specifications
without prior notice.
16/05/12
